MixingLink® - Eventide Audio

High-quality Mic Pre with FX Loop

A stompbox-size audio toolkit for on-stage, in the studio, and everywhere in between. Includes a quiet high gain mic-pre, 48V phantom power, and enough I/O and control for applications such as FX Loop for microphone signal processing (vocals, horns, strings, etc), signal splitting, and combining, complete re-amp setup, impedance, and gain matching, mixing and more.

Features

Ultimate Versatility

  • Latching or momentary footswitch control of FX loop for performance effects
  • Works with a wide range of microphones including condenser and ribbon mics with up to 65dB of clean gain
  • Aux I/O connection supporting stereo input and send
  • Guitar amp output and headphone monitor output with separate master volume control
  • International universal power supply included
  • Operates on 9V battery (no phantom power when operating on a battery)
  • 48V phantom power for condenser mics
  • Balanced XLR output which supports DI and line levels
  • Instrument and balanced line level inputs
  • Versatilemixcontrol supports 3 modes
    • 100% Dry w/FX blended in
    • Mic/FX balance control
    • 100% FX (no Dry)

A Swiss Army Knife for Every Application

Use the MixingLink as a compact studio mic pre for recording with Pro Tools, Ableton, or any other D.A.W.

Use the MixingLink to connect a microphone to your favorite stompbox(es) to add effects to your vocals.

Use the MixingLink as a hotel practice amp.

Use the MixingLink as an A/B Box to switch between two instruments.

Use MixingLink to split and blend one instrument between two amplifiers.

Use MixingLink as a mixer to connect multiple sources to an amp or headphones.

Reviews

Ideal for adventure.

Ideal for any creative and adventurous music producer looking for a new sound or technique, MixingLink is superb for interconnecting any pieces of gear together.

Barry Rudolph
Music Connection

Versatile.

Clearly, a lot of thought has gone into making the MixingLink as versatile as possible…’Swiss Army Knife’ is thoroughly deserved in this instance!

Paul White
Sound on Sound

All-in-one solution.

For those looking for an all-in-one studio and stage routing solution in a compact form factor, this is the finest option out there.

Fletcher Stewart
Tone Report Weekly

Artists Using MixingLink®

Joe Chiccarelli
U2, Elton John
Joel Hamilton
Tom Waits, The Black Keys
Lee Oskar
Lee Oskar Harmonicas
Robin Finck
Nine Inch Nails, Guns N' Roses
Stewart Lerman
Patti Smith, St. Vincent, Boardwalk Empire
Stu Brooks
Dub Trio, Matisyahu, Pretty Lights, 50 Cent, Lady Gaga, Peeping Tom, Dr. John
Timo Ellis
Netherlands, Yoko Ono, Mark Ronson
Tony Visconti
Bowie, T. Rex
Vance Powell
Jack White, Sputnik Sound
Christian Cassan
Dälek
Erin Tonkon
David Bowie, Holy Holy, Esperanza Spalding

Specifications

Analog Input
MAX Input Levels, Input Impedance

INST IN

+10dBu, 500kΩ

1/4″ Line IN

+24dBu, 22kΩ

Out 2

+4dBu, 2kΩ

EXP

+10dB, 200kΩ

AUX IN

+4dBu, 5.0kΩ

Analog Output
MAX Output Levels, Output Impedance

TO FX

+10dBu, 400Ω

TO AMP

+10dBu, 250Ω

PHONES

150mW per channel, min Load = 8 Ohms

DI/LINE OUT

(DI) -10dBu, (LINE) +18dBu, 200Ω

AUX OUT

18mV, 200Ω (mobile mic level)

Power Supply

9V DC @ 200mA / Center Negative (-), 5.5mm/2.1mm jack (BOSS standard)

Dimensions

English: 3.6” (H) x 2.65” (W) x 1.5” (D)
Metric: 91(H) x 67(W) x 38(D) mm

Weight

.96 lb / .43 kg
